Quadro 4L Behind Firewall

cembick123 · 06-29-2012, 12:59 AM

I have a Quadro 4L that is behind a firewall.......the ports have been opened for registration and I am currently able to access the IPPBX through https:....my problem is registering remote extension...i cannot get an Aastra 9133i to register to my quadro even though the ports have been setup on the firewall to allow...here is the message i am getting....any help would be appreciated:

REGISTER sip:172.22.0.5:5060 SIP/2.0
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
Max-Forwards: 70
Content-Length: 0
To: 400 <sip:400@>
From: 400 <sip:400@>;tag=20dc9309ac88f72
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
CSeq: 833602757 REGISTER
Contact: 400 <sip:400@98.199.67.27:5060;transport=udp>
Allow-Events: talk,hold,conference
Allow:NOTIFY,REFER,OPTIONS,INVITE,ACK,CANCEL,BYE,I NFO
User-Agent: Aastra 9133i/1.4.3.23 Brcm Callctrl/1.5.1.0 MxSF/v3.2.8.45

***************************** SIP message buffer end ******************************

18:54:46 TLayer::IsCanProceed # Incorrect SIP request: 52, parse status: can answer, send error response
18:54:46 Try to send SIP message # (28/06/2012 23:54:46:970 GMT) # UDP # 330 bytes # buff size 1 # from: 172.22.0.5:5060 # to: 98.199.67.27:5060

***************************** SIP message buffer start *****************************
SIP/2.0 400 Bad host name in To header field
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
From: 400 <sip:400@>;tag=20dc9309ac88f72
To: 400 <sip:400@>
CSeq: 833602757 REGISTER
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
User-Agent: Epygi Quadro SIP User Agent/v5.3.2 (QUADRO-2X2)
Content-Length: 0

***************************** SIP message buffer end ******************************

18:54:47 Receive SIP message # (28/06/2012 23:54:47:462 GMT) # UDP # 498 bytes # buff size 1 # from: 98.199.67.27:5060 # to: 172.22.0.5:5060

***************************** SIP message buffer start *****************************
REGISTER sip:172.22.0.5:5060 SIP/2.0
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
Max-Forwards: 70
Content-Length: 0
To: 400 <sip:400@>
From: 400 <sip:400@>;tag=20dc9309ac88f72
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
CSeq: 833602757 REGISTER
Contact: 400 <sip:400@98.199.67.27:5060;transport=udp>
Allow-Events: talk,hold,conference
Allow:NOTIFY,REFER,OPTIONS,INVITE,ACK,CANCEL,BYE,I NFO
User-Agent: Aastra 9133i/1.4.3.23 Brcm Callctrl/1.5.1.0 MxSF/v3.2.8.45

***************************** SIP message buffer end ******************************

18:54:47 TLayer::IsCanProceed # Incorrect SIP request: 52, parse status: can answer, send error response
18:54:47 Try to send SIP message # (28/06/2012 23:54:47:465 GMT) # UDP # 330 bytes # buff size 1 # from: 172.22.0.5:5060 # to: 98.199.67.27:5060

***************************** SIP message buffer start *****************************
SIP/2.0 400 Bad host name in To header field
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
From: 400 <sip:400@>;tag=20dc9309ac88f72
To: 400 <sip:400@>
CSeq: 833602757 REGISTER
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
User-Agent: Epygi Quadro SIP User Agent/v5.3.2 (QUADRO-2X2)
Content-Length: 0

***************************** SIP message buffer end ******************************

18:54:48 Receive SIP message # (28/06/2012 23:54:48:801 GMT) # UDP # 498 bytes # buff size 1 # from: 98.199.67.27:5060 # to: 172.22.0.5:5060

***************************** SIP message buffer start *****************************
REGISTER sip:172.22.0.5:5060 SIP/2.0
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
Max-Forwards: 70
Content-Length: 0
To: 400 <sip:400@>
From: 400 <sip:400@>;tag=20dc9309ac88f72
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
CSeq: 833602757 REGISTER
Contact: 400 <sip:400@98.199.67.27:5060;transport=udp>
Allow-Events: talk,hold,conference
Allow:NOTIFY,REFER,OPTIONS,INVITE,ACK,CANCEL,BYE,I NFO
User-Agent: Aastra 9133i/1.4.3.23 Brcm Callctrl/1.5.1.0 MxSF/v3.2.8.45

***************************** SIP message buffer end ******************************

18:54:48 TLayer::IsCanProceed # Incorrect SIP request: 52, parse status: can answer, send error response
18:54:48 Try to send SIP message # (28/06/2012 23:54:48:803 GMT) # UDP # 330 bytes # buff size 1 # from: 172.22.0.5:5060 # to: 98.199.67.27:5060

***************************** SIP message buffer start *****************************
SIP/2.0 400 Bad host name in To header field
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
From: 400 <sip:400@>;tag=20dc9309ac88f72
To: 400 <sip:400@>
CSeq: 833602757 REGISTER
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
User-Agent: Epygi Quadro SIP User Agent/v5.3.2 (QUADRO-2X2)
Content-Length: 0

***************************** SIP message buffer end ******************************

18:54:50 Receive SIP message # (28/06/2012 23:54:50:803 GMT) # UDP # 498 bytes # buff size 1 # from: 98.199.67.27:5060 # to: 172.22.0.5:5060

***************************** SIP message buffer start *****************************
REGISTER sip:172.22.0.5:5060 SIP/2.0
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
Max-Forwards: 70
Content-Length: 0
To: 400 <sip:400@>
From: 400 <sip:400@>;tag=20dc9309ac88f72
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
CSeq: 833602757 REGISTER
Contact: 400 <sip:400@98.199.67.27:5060;transport=udp>
Allow-Events: talk,hold,conference
Allow:NOTIFY,REFER,OPTIONS,INVITE,ACK,CANCEL,BYE,I NFO
User-Agent: Aastra 9133i/1.4.3.23 Brcm Callctrl/1.5.1.0 MxSF/v3.2.8.45

***************************** SIP message buffer end ******************************

18:54:50 TLayer::IsCanProceed # Incorrect SIP request: 52, parse status: can answer, send error response
18:54:50 Try to send SIP message # (28/06/2012 23:54:50:805 GMT) # UDP # 330 bytes # buff size 1 # from: 172.22.0.5:5060 # to: 98.199.67.27:5060

***************************** SIP message buffer start *****************************
SIP/2.0 400 Bad host name in To header field
Via: SIP/2.0/UDP 98.199.67.27:5060;branch=z9hG4bKfe4126e36
From: 400 <sip:400@>;tag=20dc9309ac88f72
To: 400 <sip:400@>
CSeq: 833602757 REGISTER
Call-ID: 2632463d5daec5e5d2ed43b2d77a74f9@172.16.1.2
User-Agent: Epygi Quadro SIP User Agent/v5.3.2 (QUADRO-2X2)
Content-Length: 0

***************************** SIP message buffer end ******************************

AManukyan · 07-03-2012, 03:18 PM

Hello

According to the logs on the REGISTER message Quadro answers to the phone with error message "Bad host name in To header field" because receives incorrect parameters in REGISTER message.
To: 400 <sip:400@>
From: 400 <sip:400@>
After "@" must be an IP address of Quadro on which you want to register your phone(for example "To: 400 <sip:400@172.30.0.1"). The reason can be incorrect configuration of the IP phone or maybe in your network there is something that changes these fields(TO,From) in REGISTER messages.

Thanks.
