FXO Disconnect Settings SA - Page 2

davrays · 10-03-2011, 05:11 PM

Kristoph, first of all - what did you change to solve the FXO problem? Did you try anything I wrote above or the problem resolved itself somehow?
After writing the long text above, I am interested to know what was the reason of the issue, and whether something I suggested did help or not...

Second - if phones continue ring after disconnecting SIP call, then you may have network problem at your intallation. Look at the SIP logs.

Kristoph · 10-18-2011, 01:28 PM

Sorry for not replying so long I was out of office. Your suggestion helped with PSTN calls, but had no influence on SIP calls.

I can send you some logs but I need to know which ones.

davrays · 10-18-2011, 01:55 PM

Its extremely strange that you hav such problem with SIP calls. I don't see any reason for this other than delayd response from ITSP or some network problem (big delays in network because of huge traffic or connectivity problems, like loops, collisions or ip conflict).

You could go to "System->Diagnostics->Show System Logs", marks the logs (press "Mark the Logs" button), make a call to reproduce the problem (make a call, wait 1-2 seconds to listen a ringing, then hangup, make sure the ringing continues for 3-4 seconds after that), then mark the logs again. Copy the "SIP Agent Logs" in between two mark signs, and paste them here. We could see which of the SIP messages was delayed, and whether it has delayed at all...

Kristoph · 10-18-2011, 04:55 PM

Here we go

<<======================LOGS MARKER======================>>
<<================================================ =======>>
<<User's Comment: SIP disconnect test start1>>
<<================================================ =======>>
14:27:02 Receive SIP message # (18/10/2011 12:27:02:833 GMT) # UDP # 954 bytes # buff size 0 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2f4be87a;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 102 INVITE
User-Agent: DHGW
Date: Tue, 18 Oct 2011 12:27:02 GMT
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO
Supported: replaces, timer
Content-Type: application/sdp
Content-Length: 393

v=0
o=root 1004707011 1004707011 IN IP4 SIPserver
s=Asterisk PBX 1.6.2.9-2+squeeze3
c=IN IP4 SIPserver
t=0 0
m=audio 12900 RTP/AVP 0 111 4 18 8 101
a=rtpmap:0 PCMU/8000
a=rtpmap:111 G726-32/8000
a=rtpmap:4 G723/8000
a=fmtp:4 annexa=no
a=rtpmap:18 G729/8000
a=fmtp:18 annexb=no
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
a=ptime:20
a=sendrecv
***************************** SIP message buffer end ******************************

14:27:02 Try to send SIP message # (18/10/2011 12:27:02:837 GMT) # UDP # 289 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 100 Trying
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a
To: <sip:SIPnumber@QuadroIP:5060>
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 102 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:02 TLayer::MsgToTU # Msg type: 51 # TID: 2057128 # DID: 0
14:27:02 UACore::TLReqMsgProc # Got INVITE SIP request
14:27:02 SipSessDlg: # Call ID Info # SID: 5664807695850202111 # 14:27:02 SipID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
14:27:02 SipSessDlg::ChangeSessTimerFlag # user caller1 # SessionTimer = 0
14:27:02 Receive SIP message # (18/10/2011 12:27:02:855 GMT) # UDP # 956 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
INVITE sip:SIPnumber-1@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
To: <sip:SIPnumber-1@QuadroIP:5060>
Contact: <sip:caller1@SIPserver>
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
CSeq: 102 INVITE
User-Agent: DHGW
Date: Tue, 18 Oct 2011 12:27:02 GMT
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO
Supported: replaces, timer
Content-Type: application/sdp
Content-Length: 391

v=0
o=root 684655146 684655146 IN IP4 SIPserver
s=Asterisk PBX 1.6.2.9-2+squeeze3
c=IN IP4 SIPserver
t=0 0
m=audio 18640 RTP/AVP 0 111 4 18 8 101
a=rtpmap:0 PCMU/8000
a=rtpmap:111 G726-32/8000
a=rtpmap:4 G723/8000
a=fmtp:4 annexa=no
a=rtpmap:18 G729/8000
a=fmtp:18 annexb=no
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
a=ptime:20
a=sendrecv
***************************** SIP message buffer end ******************************

14:27:02 Try to send SIP message # (18/10/2011 12:27:02:858 GMT) # UDP # 291 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 100 Trying
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc
To: <sip:SIPnumber-1@QuadroIP:5060>
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
CSeq: 102 INVITE
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:02 TLayer::MsgToTU # Msg type: 51 # TID: 2057130 # DID: 0
14:27:02 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111
14:27:02 TargetQualifier::QualifyTargets # Try to qualify targets for dest SIPserver # OID: 2057129
14:27:02 TargetQualifier::NatHandling # Don't need nat settings - nat disconnected # OID: 2057129
14:27:02 SipSessDlg::IncInviteProc # mLocalParams.mHostAddr = QuadroIP localHostName = quadro.epygi-config.com OID: 2057129 # SID: 5664807695850202111
14:27:02 UA --> CM # MakeCall # from: caller1@SIPserver:, to: SIPnumber, child: (empty), media exist, GUID: (empty) # ContactInfo: SIPserver # SID: 5664807695850202111
14:27:03 CM --> UA # OnUpdateUserInfo # OID: 2057129 # SID: 5664807695850202111
14:27:03 UACore::TLReqMsgProc # Got INVITE SIP request
14:27:03 SipSessDlg: # Call ID Info # SID: 5664807700144356199 # 14:27:03 SipID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
14:27:03 SipSessDlg::ChangeSessTimerFlag # user caller1 # SessionTimer = 0
14:27:03 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057131 # SID: 5664807700144356199
14:27:03 TargetQualifier::QualifyTargets # Try to qualify targets for dest SIPserver # OID: 2057131
14:27:03 TargetQualifier::NatHandling # Don't need nat settings - nat disconnected # OID: 2057131
14:27:03 SipSessDlg::IncInviteProc # mLocalParams.mHostAddr = QuadroIP localHostName = quadro.epygi-config.com OID: 2057131 # SID: 5664807700144356199
14:27:03 UA --> CM # MakeCall # from: caller1@SIPserver:, to: SIPnumber-1, child: (empty), media exist, GUID: (empty) # ContactInfo: SIPserver # SID: 5664807700144356199
14:27:03 CM --> UA # OnRinging # Media not exist # OID: 2057129 # SID: 5664807695850202111
14:27:03 Try to send SIP message # (18/10/2011 12:27:03:164 GMT) # UDP # 448 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 180 Ringing
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 102 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Contact: <sip:SIPnumber@QuadroIP:5060>
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:03 CM --> UA # OnUpdateUserInfo # OID: 2057131 # SID: 5664807700144356199
14:27:03 CM --> UA # OnRinging # Media not exist # OID: 2057131 # SID: 5664807700144356199
14:27:03 Try to send SIP message # (18/10/2011 12:27:03:184 GMT) # UDP # 452 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 180 Ringing
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc
To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
CSeq: 102 INVITE
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
Contact: <sip:SIPnumber-1@QuadroIP:5060>
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:03 CM --> UA # OnAccept # Media exist #OID: 2057129 # SID: 5664807695850202111
14:27:03 SipSessDlg::SelfMediaHandling # State: complete, Sesssion Key: empty # OID: 2057129 # SID: 5664807695850202111
14:27:04 Try to send SIP message # (18/10/2011 12:27:03:1000 GMT) # UDP # 811 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 200 OK
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 102 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Allow: INVITE, ACK, CANCEL, BYE, OPTIONS, INFO, SUBSCRIBE, NOTIFY, REFER, MESSAGE, UPDATE
Contact: <sip:SIPnumber@QuadroIP:5060>
Content-Type: application/sdp
Supported: replaces, norefersub
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 211

v=0
o=- 877 388 IN IP4 QuadroIP
s=-
c=IN IP4 QuadroIP
t=0 0
m=audio 6024 RTP/AVP 0 8 101
a=ptime:20
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
***************************** SIP message buffer end ******************************

14:27:04 Receive SIP message # (18/10/2011 12:27:04:013 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK4e88b46d;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 102 ACK
User-Agent: DHGW
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 TLayer::MsgToTU # Msg type: 55 # TID: 2057128 # DID: 2057129
14:27:04 UACore::TLReqMsgProc # Got ACK SIP request
14:27:04 SipSessDlg::IncAckProc # Got ACK message # OID: 2057129 # SID: 5664807695850202111
14:27:04 UA --> CM # Done # media not exist # SID: 5664807695850202111
14:27:04 Receive SIP message # (18/10/2011 12:27:04:045 GMT) # UDP # 409 bytes # buff size 2 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
CANCEL sip:SIPnumber-1@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
To: <sip:SIPnumber-1@QuadroIP:5060>
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
CSeq: 102 CANCEL
User-Agent: DHGW
Reason: SIP;cause=200;text="Call completed elsewhere"
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 TLayer::MsgToTU # Msg type: 53 # TID: 2057132 # DID: 0
14:27:04 UACore::TLReqMsgProc # Got CANCEL SIP request
14:27:04 SipSessDlg::IncCancelProc # Got CANCEL message # OID: 2057131 # SID: 5664807700144356199
14:27:04 Receive SIP message # (18/10/2011 12:27:04:053 GMT) # UDP # 848 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2f483c58;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 103 INVITE
User-Agent: DHGW
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO
Supported: replaces, timer
Content-Type: application/sdp
Content-Length: 273

v=0
o=root 1004707011 1004707012 IN IP4 91.202.124.51
s=Asterisk PBX 1.6.2.9-2+squeeze3
c=IN IP4 91.202.124.51
t=0 0
m=audio 12640 RTP/AVP 0 8 101
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
a=ptime:20
a=sendrecv
***************************** SIP message buffer end ******************************

14:27:04 Try to send SIP message # (18/10/2011 12:27:04:160 GMT) # UDP # 340 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 100 Trying
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f483c58
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 103 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 TLayer::MsgToTU # Msg type: 51 # TID: 2057133 # DID: 0
14:27:04 Try to send SIP message # (18/10/2011 12:27:04:195 GMT) # UDP # 399 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 200 OK
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc
To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
CSeq: 102 CANCEL
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 Try to send SIP message # (18/10/2011 12:27:04:201 GMT) # UDP # 415 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 487 Request Terminated
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc
To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
CSeq: 102 INVITE
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 UA --> CM # CloseCall # reason: Got CANCEL message # SID: 5664807700144356199
14:27:04 Receive SIP message # (18/10/2011 12:27:04:224 GMT) # UDP # 438 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
ACK sip:SIPnumber-1@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1
To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b
Contact: <sip:caller1@SIPserver>
Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver
CSeq: 102 ACK
User-Agent: DHGW
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 SipSessDlg::TerminateTransactions # OID: 2057131 # SIPID: 478453cb2d45990a13a75e2d108fd95a@SIPserver # SID: 5664807700144356199
14:27:04 CallsAgent::MsgFromCM # Got 4 message from CM for unknown call
14:27:04 UA --> CM # ReportError # Error: NoSuchCall # Sip error: 0 # SID: 5664807700144356199
14:27:04 UACore::TLReqMsgProc # Got INVITE SIP request
14:27:04 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111
14:27:04 UA --> CM # ChangeMedia # media exist # SID: 5664807695850202111
14:27:04 CM --> UA # OnAccept # Media exist #OID: 2057129 # SID: 5664807695850202111
14:27:04 SipSessDlg::SelfMediaHandling # State: complete, Sesssion Key: empty # OID: 2057129 # SID: 5664807695850202111
14:27:04 Try to send SIP message # (18/10/2011 12:27:04:270 GMT) # UDP # 720 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 200 OK
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f483c58
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 103 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Contact: <sip:SIPnumber@QuadroIP:5060>
Content-Type: application/sdp
Supported: replaces, norefersub
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 211

v=0
o=- 877 389 IN IP4 QuadroIP
s=-
c=IN IP4 QuadroIP
t=0 0
m=audio 6024 RTP/AVP 0 8 101
a=ptime:20
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
***************************** SIP message buffer end ******************************

14:27:04 Receive SIP message # (18/10/2011 12:27:04:313 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK13eed06b;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 103 ACK
User-Agent: DHGW
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:04 TLayer::MsgToTU # Msg type: 55 # TID: 2057133 # DID: 2057129
14:27:04 UACore::TLReqMsgProc # Got ACK SIP request
14:27:04 SipSessDlg::IncAckProc # Got ACK message # OID: 2057129 # SID: 5664807695850202111
14:27:04 UA --> CM # Done # media not exist # SID: 5664807695850202111
14:27:15 Receive SIP message # (18/10/2011 12:27:15:147 GMT) # UDP # 846 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2b4af37b;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 104 INVITE
User-Agent: DHGW
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO
Supported: replaces, timer
Content-Type: application/sdp
Content-Length: 271

v=0
o=root 1004707011 1004707013 IN IP4 SIPserver
s=Asterisk PBX 1.6.2.9-2+squeeze3
c=IN IP4 SIPserver
t=0 0
m=audio 12900 RTP/AVP 0 8 101
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
a=ptime:20
a=sendrecv
***************************** SIP message buffer end ******************************

14:27:15 Try to send SIP message # (18/10/2011 12:27:15:151 GMT) # UDP # 340 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 100 Trying
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2b4af37b
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 104 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:15 TLayer::MsgToTU # Msg type: 51 # TID: 2057134 # DID: 0
14:27:15 UACore::TLReqMsgProc # Got INVITE SIP request
14:27:15 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111
14:27:15 UA --> CM # ChangeMedia # media exist # SID: 5664807695850202111
14:27:15 CM --> UA # OnReportError # Error: RequestRejected # SIP error: 0 # OID: 2057129 # SID: 5664807695850202111
14:27:15 Try to send SIP message # (18/10/2011 12:27:15:172 GMT) # UDP # 414 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
SIP/2.0 488 Not Acceptable Here
Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2b4af37b
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
CSeq: 104 INVITE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:15 Receive SIP message # (18/10/2011 12:27:15:184 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0
Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2b4af37b;rport
Max-Forwards: 70
From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
Contact: <sip:caller1@SIPserver>
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 104 ACK
User-Agent: DHGW
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:43 CM --> UA # OnCloseCall # OID: 2057129 # SID: 5664807695850202111
14:27:43 SipSessDlg::TerminateTransactions # OID: 2057129 # SIPID: 46fdc7537bc2f95135e871ab03f14545@SIPserver # SID: 0
14:27:43 Try to send SIP message # (18/10/2011 12:27:43:810 GMT) # UDP # 470 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060

***************************** SIP message buffer start *****************************
BYE sip:caller1@SIPserver SIP/2.0
Via: SIP/2.0/UDP QuadroIP:5060;rport;branch=z9hG4bKEPSVBUS05aae88c-4171-45e1-b48c-d26323ef3c5a
To: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
From: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
CSeq: 931 BYE
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
User-Agent: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X)
Max-Forwards: 70
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:43 Receive SIP message # (18/10/2011 12:27:43:821 GMT) # UDP # 539 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060

***************************** SIP message buffer start *****************************
SIP/2.0 481 Call leg/transaction does not exist
Via: SIP/2.0/UDP QuadroIP:5060;branch=z9hG4bKEPSVBUS05aae88c-4171-45e1-b48c-d26323ef3c5a;received=QuadroIP;rport=5060
From: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4
To: "caller1" <sip:caller1@SIPserver>;tag=as6682c795
Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver
CSeq: 931 BYE
Server: DHGW
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO
Supported: replaces, timer
Content-Length: 0

***************************** SIP message buffer end ******************************

14:27:43 TLayer::MsgToTU # Msg type: 481 # TID: 2057233 # DID: 2057129
14:27:43 SipSessDlg::Inc4xxProc # Got 481 message # OID: 2057129 # SID: 0
14:27:43 SipSessDlg::Inc4xxProc # Call incorrect termination # Got 481 error message for BYE request # OID: 2057129 # SID: 0
14:27:43 SipSessDlg::TerminateTransactions # OID: 2057129 # SIPID: 46fdc7537bc2f95135e871ab03f14545@SIPserver # SID: 0
<<================================================ =======>>
<<======================LOGS MARKER======================>>
<<================================================ =======>>
<<User's Comment: SIP disconnect test stop1>>
<<================================================ =======>>

changed for security reasons:
caller1 = caller's number (it was GSM phone)
quadroIP = my quadro IP address
SIPnumber = my sip numer
SIPnumber-1 = secondary sip number used for outgoing calls
SIPserver = Sip server IP

davrays · 10-18-2011, 05:45 PM

Let me understand first:

1. In this logs the messages are sent from "QuadroIP" to "QuadroIP", so there is just one IP address, and the IP of Asterisk server (is that the ITSP?) is not visible. How that happened? Did you replace two different IP addresses in logs with the same "QuadroIP" word?

2. There is no ringing at all in those logs. The quadro accepted the call almost immediately, and there is no ringing process. What was the destination of the call - is that an Autoattendant, or voicemail, or FXS phone or something different?
To be short, could you please describe the call by words (what was the calling device; was the call from ITSP or some other device; what was the destination; how long it rang; how long you waited until hanging up the calling phone; when did you hangup - during the ringing, or when the call was already established)?

Kristoph · 10-19-2011, 09:06 AM

You are right, sorry for this, similar IP addresses, my bad.

davrays · 10-19-2011, 09:42 PM

Thanks for correcting the logs.... What about my second question?

Kristoph · 10-24-2011, 03:06 PM

Testing routine:

All incoming calls go to "00" when the caller gets the welcome message he chooses the extension he wants to ring. In this test it was "14" so the caller had to choose "014" to bypass the regular menu in the autoattendant.

If you wouldlike I can send you what was recorded in th voice mailbox when the caller disconnected before the call was answered.

davrays · 10-24-2011, 07:11 PM

Well, if this is the test scenario, then you can clearly see in the logs above that the problem is in the SIP server (it looks to be a kind of Asterisk machine). As you tell, you have hang up the calling phone (at the Asterisk side), but we don't see any BYE message coming from the Asterisk machine. Thats why Quadro is not informed that you have hangup the calling phone, and so the call stays active on the Quadro (so you have a voicemail recorded). After timeout the call was closed by Quadro itself, and you can see at this point the Astreisk server told it doesn't know anything about that call ("481 Call leg/transaction does not exist" message).

So my assumptions are the following:
It looks like the Asterisk machine have closed this call locally after getting "488 Not Acceptable Here" response ftrom Quadro at 14:27:15. But Asterisk did that silently, without sending any "close" message to Quadro. This is incorrect behaviour from that server machine side (as it SHOULD send "BYE" message). I suppose this is a bug in that server software.

Now about what you can do to fix this problem:
1. you either have to find somebody to fix the problem in Asterisk (so it doesn't silently close the call after getting "488 Not Acceptable Here"),
or
2. find out why the Asterisk server sends the mid-call re-INVITE message at 14:27:15, which causes this problem (as it causes Quadro to send the 488 response), and configure the server not to send those re-INVITES. I suppose this could be some kind of session timer initiated from Astyerisk machine. Probably you have to disable that.

In any case - you have to look for the problem in the Asterisk server software, but not in the Quadro.

Kristoph · 10-26-2011, 10:02 AM

I will contact the SIP provider and show them the conclusion you came to, hopefully they can fix the problem.

Thank you for your time!

10-18-2011, 04:55 PM	#14
Kristoph Junior Member Join Date: Sep 2009 Posts: 21	Here we go <<======================LOGS MARKER======================>> <<================================================ =======>> <<User's Comment: SIP disconnect test start1>> <<================================================ =======>> 14:27:02 Receive SIP message # (18/10/2011 12:27:02:833 GMT) # UDP # 954 bytes # buff size 0 # from: SIPserver:5060 # to: QuadroIP:5060 *************************** SIP message buffer start ************************* INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2f4be87a;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060> Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 102 INVITE User-Agent: DHGW Date: Tue, 18 Oct 2011 12:27:02 GMT Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO Supported: replaces, timer Content-Type: application/sdp Content-Length: 393 v=0 o=root 1004707011 1004707011 IN IP4 SIPserver s=Asterisk PBX 1.6.2.9-2+squeeze3 c=IN IP4 SIPserver t=0 0 m=audio 12900 RTP/AVP 0 111 4 18 8 101 a=rtpmap:0 PCMU/8000 a=rtpmap:111 G726-32/8000 a=rtpmap:4 G723/8000 a=fmtp:4 annexa=no a=rtpmap:18 G729/8000 a=fmtp:18 annexb=no a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 a=ptime:20 a=sendrecv ************************* SIP message buffer end ************************** 14:27:02 Try to send SIP message # (18/10/2011 12:27:02:837 GMT) # UDP # 289 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 100 Trying Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a To: <sip:SIPnumber@QuadroIP:5060> From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 102 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:02 TLayer::MsgToTU # Msg type: 51 # TID: 2057128 # DID: 0 14:27:02 UACore::TLReqMsgProc # Got INVITE SIP request 14:27:02 SipSessDlg: # Call ID Info # SID: 5664807695850202111 # 14:27:02 SipID: 46fdc7537bc2f95135e871ab03f14545@SIPserver 14:27:02 SipSessDlg::ChangeSessTimerFlag # user caller1 # SessionTimer = 0 14:27:02 Receive SIP message # (18/10/2011 12:27:02:855 GMT) # UDP # 956 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* INVITE sip:SIPnumber-1@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 To: <sip:SIPnumber-1@QuadroIP:5060> Contact: <sip:caller1@SIPserver> Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver CSeq: 102 INVITE User-Agent: DHGW Date: Tue, 18 Oct 2011 12:27:02 GMT Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO Supported: replaces, timer Content-Type: application/sdp Content-Length: 391 v=0 o=root 684655146 684655146 IN IP4 SIPserver s=Asterisk PBX 1.6.2.9-2+squeeze3 c=IN IP4 SIPserver t=0 0 m=audio 18640 RTP/AVP 0 111 4 18 8 101 a=rtpmap:0 PCMU/8000 a=rtpmap:111 G726-32/8000 a=rtpmap:4 G723/8000 a=fmtp:4 annexa=no a=rtpmap:18 G729/8000 a=fmtp:18 annexb=no a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 a=ptime:20 a=sendrecv ************************* SIP message buffer end ************************** 14:27:02 Try to send SIP message # (18/10/2011 12:27:02:858 GMT) # UDP # 291 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 100 Trying Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc To: <sip:SIPnumber-1@QuadroIP:5060> From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 CSeq: 102 INVITE Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:02 TLayer::MsgToTU # Msg type: 51 # TID: 2057130 # DID: 0 14:27:02 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111 14:27:02 TargetQualifier::QualifyTargets # Try to qualify targets for dest SIPserver # OID: 2057129 14:27:02 TargetQualifier::NatHandling # Don't need nat settings - nat disconnected # OID: 2057129 14:27:02 SipSessDlg::IncInviteProc # mLocalParams.mHostAddr = QuadroIP localHostName = quadro.epygi-config.com OID: 2057129 # SID: 5664807695850202111 14:27:02 UA --> CM # MakeCall # from: caller1@SIPserver:, to: SIPnumber, child: (empty), media exist, GUID: (empty) # ContactInfo: SIPserver # SID: 5664807695850202111 14:27:03 CM --> UA # OnUpdateUserInfo # OID: 2057129 # SID: 5664807695850202111 14:27:03 UACore::TLReqMsgProc # Got INVITE SIP request 14:27:03 SipSessDlg: # Call ID Info # SID: 5664807700144356199 # 14:27:03 SipID: 478453cb2d45990a13a75e2d108fd95a@SIPserver 14:27:03 SipSessDlg::ChangeSessTimerFlag # user caller1 # SessionTimer = 0 14:27:03 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057131 # SID: 5664807700144356199 14:27:03 TargetQualifier::QualifyTargets # Try to qualify targets for dest SIPserver # OID: 2057131 14:27:03 TargetQualifier::NatHandling # Don't need nat settings - nat disconnected # OID: 2057131 14:27:03 SipSessDlg::IncInviteProc # mLocalParams.mHostAddr = QuadroIP localHostName = quadro.epygi-config.com OID: 2057131 # SID: 5664807700144356199 14:27:03 UA --> CM # MakeCall # from: caller1@SIPserver:, to: SIPnumber-1, child: (empty), media exist, GUID: (empty) # ContactInfo: SIPserver # SID: 5664807700144356199 14:27:03 CM --> UA # OnRinging # Media not exist # OID: 2057129 # SID: 5664807695850202111 14:27:03 Try to send SIP message # (18/10/2011 12:27:03:164 GMT) # UDP # 448 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 180 Ringing Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 102 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Contact: <sip:SIPnumber@QuadroIP:5060> Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:03 CM --> UA # OnUpdateUserInfo # OID: 2057131 # SID: 5664807700144356199 14:27:03 CM --> UA # OnRinging # Media not exist # OID: 2057131 # SID: 5664807700144356199 14:27:03 Try to send SIP message # (18/10/2011 12:27:03:184 GMT) # UDP # 452 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 180 Ringing Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 CSeq: 102 INVITE Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver Contact: <sip:SIPnumber-1@QuadroIP:5060> Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:03 CM --> UA # OnAccept # Media exist #OID: 2057129 # SID: 5664807695850202111 14:27:03 SipSessDlg::SelfMediaHandling # State: complete, Sesssion Key: empty # OID: 2057129 # SID: 5664807695850202111 14:27:04 Try to send SIP message # (18/10/2011 12:27:03:1000 GMT) # UDP # 811 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 200 OK Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f4be87a To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 102 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Allow: INVITE, ACK, CANCEL, BYE, OPTIONS, INFO, SUBSCRIBE, NOTIFY, REFER, MESSAGE, UPDATE Contact: <sip:SIPnumber@QuadroIP:5060> Content-Type: application/sdp Supported: replaces, norefersub Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 211 v=0 o=- 877 388 IN IP4 QuadroIP s=- c=IN IP4 QuadroIP t=0 0 m=audio 6024 RTP/AVP 0 8 101 a=ptime:20 a=rtpmap:0 PCMU/8000 a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 ************************* SIP message buffer end ************************** 14:27:04 Receive SIP message # (18/10/2011 12:27:04:013 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK4e88b46d;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 102 ACK User-Agent: DHGW Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 TLayer::MsgToTU # Msg type: 55 # TID: 2057128 # DID: 2057129 14:27:04 UACore::TLReqMsgProc # Got ACK SIP request 14:27:04 SipSessDlg::IncAckProc # Got ACK message # OID: 2057129 # SID: 5664807695850202111 14:27:04 UA --> CM # Done # media not exist # SID: 5664807695850202111 14:27:04 Receive SIP message # (18/10/2011 12:27:04:045 GMT) # UDP # 409 bytes # buff size 2 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* CANCEL sip:SIPnumber-1@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 To: <sip:SIPnumber-1@QuadroIP:5060> Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver CSeq: 102 CANCEL User-Agent: DHGW Reason: SIP;cause=200;text="Call completed elsewhere" Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 TLayer::MsgToTU # Msg type: 53 # TID: 2057132 # DID: 0 14:27:04 UACore::TLReqMsgProc # Got CANCEL SIP request 14:27:04 SipSessDlg::IncCancelProc # Got CANCEL message # OID: 2057131 # SID: 5664807700144356199 14:27:04 Receive SIP message # (18/10/2011 12:27:04:053 GMT) # UDP # 848 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2f483c58;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 103 INVITE User-Agent: DHGW Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO Supported: replaces, timer Content-Type: application/sdp Content-Length: 273 v=0 o=root 1004707011 1004707012 IN IP4 91.202.124.51 s=Asterisk PBX 1.6.2.9-2+squeeze3 c=IN IP4 91.202.124.51 t=0 0 m=audio 12640 RTP/AVP 0 8 101 a=rtpmap:0 PCMU/8000 a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 a=ptime:20 a=sendrecv ************************* SIP message buffer end ************************** 14:27:04 Try to send SIP message # (18/10/2011 12:27:04:160 GMT) # UDP # 340 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 100 Trying Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f483c58 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 103 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 TLayer::MsgToTU # Msg type: 51 # TID: 2057133 # DID: 0 14:27:04 Try to send SIP message # (18/10/2011 12:27:04:195 GMT) # UDP # 399 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 200 OK Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 CSeq: 102 CANCEL Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 Try to send SIP message # (18/10/2011 12:27:04:201 GMT) # UDP # 415 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 487 Request Terminated Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK7e3154cc To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 CSeq: 102 INVITE Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 UA --> CM # CloseCall # reason: Got CANCEL message # SID: 5664807700144356199 14:27:04 Receive SIP message # (18/10/2011 12:27:04:224 GMT) # UDP # 438 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* ACK sip:SIPnumber-1@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK7e3154cc;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as35065dc1 To: <sip:SIPnumber-1@QuadroIP:5060>;tag=1317644155c017bfec-b0dc-4ff4-b02f-31a8b0b5b94b Contact: <sip:caller1@SIPserver> Call-ID: 478453cb2d45990a13a75e2d108fd95a@SIPserver CSeq: 102 ACK User-Agent: DHGW Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 SipSessDlg::TerminateTransactions # OID: 2057131 # SIPID: 478453cb2d45990a13a75e2d108fd95a@SIPserver # SID: 5664807700144356199 14:27:04 CallsAgent::MsgFromCM # Got 4 message from CM for unknown call 14:27:04 UA --> CM # ReportError # Error: NoSuchCall # Sip error: 0 # SID: 5664807700144356199 14:27:04 UACore::TLReqMsgProc # Got INVITE SIP request 14:27:04 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111 14:27:04 UA --> CM # ChangeMedia # media exist # SID: 5664807695850202111 14:27:04 CM --> UA # OnAccept # Media exist #OID: 2057129 # SID: 5664807695850202111 14:27:04 SipSessDlg::SelfMediaHandling # State: complete, Sesssion Key: empty # OID: 2057129 # SID: 5664807695850202111 14:27:04 Try to send SIP message # (18/10/2011 12:27:04:270 GMT) # UDP # 720 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 200 OK Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2f483c58 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 103 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Contact: <sip:SIPnumber@QuadroIP:5060> Content-Type: application/sdp Supported: replaces, norefersub Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 211 v=0 o=- 877 389 IN IP4 QuadroIP s=- c=IN IP4 QuadroIP t=0 0 m=audio 6024 RTP/AVP 0 8 101 a=ptime:20 a=rtpmap:0 PCMU/8000 a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 ************************* SIP message buffer end ************************** 14:27:04 Receive SIP message # (18/10/2011 12:27:04:313 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK13eed06b;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 103 ACK User-Agent: DHGW Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:04 TLayer::MsgToTU # Msg type: 55 # TID: 2057133 # DID: 2057129 14:27:04 UACore::TLReqMsgProc # Got ACK SIP request 14:27:04 SipSessDlg::IncAckProc # Got ACK message # OID: 2057129 # SID: 5664807695850202111 14:27:04 UA --> CM # Done # media not exist # SID: 5664807695850202111 14:27:15 Receive SIP message # (18/10/2011 12:27:15:147 GMT) # UDP # 846 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* INVITE sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2b4af37b;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 104 INVITE User-Agent: DHGW Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO Supported: replaces, timer Content-Type: application/sdp Content-Length: 271 v=0 o=root 1004707011 1004707013 IN IP4 SIPserver s=Asterisk PBX 1.6.2.9-2+squeeze3 c=IN IP4 SIPserver t=0 0 m=audio 12900 RTP/AVP 0 8 101 a=rtpmap:0 PCMU/8000 a=rtpmap:8 PCMA/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-16 a=ptime:20 a=sendrecv ************************* SIP message buffer end ************************** 14:27:15 Try to send SIP message # (18/10/2011 12:27:15:151 GMT) # UDP # 340 bytes # buff size 1 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 100 Trying Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2b4af37b To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 104 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:15 TLayer::MsgToTU # Msg type: 51 # TID: 2057134 # DID: 0 14:27:15 UACore::TLReqMsgProc # Got INVITE SIP request 14:27:15 SipSessDlg::IncInviteProc # Got INVITE message # OID: 2057129 # SID: 5664807695850202111 14:27:15 UA --> CM # ChangeMedia # media exist # SID: 5664807695850202111 14:27:15 CM --> UA # OnReportError # Error: RequestRejected # SIP error: 0 # OID: 2057129 # SID: 5664807695850202111 14:27:15 Try to send SIP message # (18/10/2011 12:27:15:172 GMT) # UDP # 414 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* SIP/2.0 488 Not Acceptable Here Via: SIP/2.0/UDP SIPserver:5060;rport=5060;branch=z9hG4bK2b4af37b To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 CSeq: 104 INVITE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver Server: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:15 Receive SIP message # (18/10/2011 12:27:15:184 GMT) # UDP # 434 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* ACK sip:SIPnumber@QuadroIP:5060 SIP/2.0 Via: SIP/2.0/UDP SIPserver:5060;branch=z9hG4bK2b4af37b;rport Max-Forwards: 70 From: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 To: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 Contact: <sip:caller1@SIPserver> Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 104 ACK User-Agent: DHGW Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:43 CM --> UA # OnCloseCall # OID: 2057129 # SID: 5664807695850202111 14:27:43 SipSessDlg::TerminateTransactions # OID: 2057129 # SIPID: 46fdc7537bc2f95135e871ab03f14545@SIPserver # SID: 0 14:27:43 Try to send SIP message # (18/10/2011 12:27:43:810 GMT) # UDP # 470 bytes # buff size 0 # from: QuadroIP:5060 # to: SIPserver:5060 ************************* SIP message buffer start ************************* BYE sip:caller1@SIPserver SIP/2.0 Via: SIP/2.0/UDP QuadroIP:5060;rport;branch=z9hG4bKEPSVBUS05aae88c-4171-45e1-b48c-d26323ef3c5a To: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 From: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 CSeq: 931 BYE Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver User-Agent: Epygi Quadro SIP User Agent/v5.1.39 (QUADRO-4X/16X) Max-Forwards: 70 Content-Length: 0 ************************* SIP message buffer end ************************** 14:27:43 Receive SIP message # (18/10/2011 12:27:43:821 GMT) # UDP # 539 bytes # buff size 1 # from: SIPserver:5060 # to: QuadroIP:5060 ************************* SIP message buffer start ************************* SIP/2.0 481 Call leg/transaction does not exist Via: SIP/2.0/UDP QuadroIP:5060;branch=z9hG4bKEPSVBUS05aae88c-4171-45e1-b48c-d26323ef3c5a;received=QuadroIP;rport=5060 From: <sip:SIPnumber@QuadroIP:5060>;tag=1317644155035723 66-4d6e-4254-8a17-96f6626826c4 To: "caller1" <sip:caller1@SIPserver>;tag=as6682c795 Call-ID: 46fdc7537bc2f95135e871ab03f14545@SIPserver CSeq: 931 BYE Server: DHGW Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY, INFO Supported: replaces, timer Content-Length: 0 ************************* SIP message buffer end **************************** 14:27:43 TLayer::MsgToTU # Msg type: 481 # TID: 2057233 # DID: 2057129 14:27:43 SipSessDlg::Inc4xxProc # Got 481 message # OID: 2057129 # SID: 0 14:27:43 SipSessDlg::Inc4xxProc # Call incorrect termination # Got 481 error message for BYE request # OID: 2057129 # SID: 0 14:27:43 SipSessDlg::TerminateTransactions # OID: 2057129 # SIPID: 46fdc7537bc2f95135e871ab03f14545@SIPserver # SID: 0 <<================================================ =======>> <<======================LOGS MARKER======================>> <<================================================ =======>> <<User's Comment: SIP disconnect test stop1>> <<================================================ =======>> changed for security reasons: caller1 = caller's number (it was GSM phone) quadroIP = my quadro IP address SIPnumber = my sip numer SIPnumber-1 = secondary sip number used for outgoing calls SIPserver = Sip server IP Last edited by Kristoph : 10-19-2011 at 09:05 AM. Reason: corrected sip server

10-24-2011, 03:06 PM	#18
Kristoph Junior Member Join Date: Sep 2009 Posts: 21	Testing routine: All incoming calls go to "00" when the caller gets the welcome message he chooses the extension he wants to ring. In this test it was "14" so the caller had to choose "014" to bypass the regular menu in the autoattendant. If you wouldlike I can send you what was recorded in th voice mailbox when the caller disconnected before the call was answered. Last edited by Kristoph : 10-24-2011 at 03:09 PM.

Thread Tools
Show Printable Version Email this Page
Display Modes
Linear Mode Switch to Hybrid Mode Switch to Threaded Mode

Similar Threads
Thread	Thread Starter	Forum	Replies	Last Post
FXO cfg settings	coimsamx	Problem Report	2	03-29-2011 07:53 AM
Pennytel SMS settings	esscom	'How Do I' Questions	0	03-31-2009 03:27 AM
Intercom in User settings	ssteiner	Installation	19	02-13-2008 07:52 AM
codec settings	mheller	Suggestions and Feedback	7	11-27-2007 12:49 AM
How to customize Extension settings?	pcavantage	'How Do I' Questions	3	10-29-2007 08:59 AM

10-03-2011, 05:11 PM	#11
davrays Quadro Architect Join Date: Jun 2006 Location: Around myself Posts: 2,083	Kristoph, first of all - what did you change to solve the FXO problem? Did you try anything I wrote above or the problem resolved itself somehow? After writing the long text above, I am interested to know what was the reason of the issue, and whether something I suggested did help or not... Second - if phones continue ring after disconnecting SIP call, then you may have network problem at your intallation. Look at the SIP logs.

10-18-2011, 01:28 PM	#12
Kristoph Junior Member Join Date: Sep 2009 Posts: 21	Sorry for not replying so long I was out of office. Your suggestion helped with PSTN calls, but had no influence on SIP calls. I can send you some logs but I need to know which ones.

10-18-2011, 01:55 PM	#13
davrays Quadro Architect Join Date: Jun 2006 Location: Around myself Posts: 2,083	Its extremely strange that you hav such problem with SIP calls. I don't see any reason for this other than delayd response from ITSP or some network problem (big delays in network because of huge traffic or connectivity problems, like loops, collisions or ip conflict). You could go to "System->Diagnostics->Show System Logs", marks the logs (press "Mark the Logs" button), make a call to reproduce the problem (make a call, wait 1-2 seconds to listen a ringing, then hangup, make sure the ringing continues for 3-4 seconds after that), then mark the logs again. Copy the "SIP Agent Logs" in between two mark signs, and paste them here. We could see which of the SIP messages was delayed, and whether it has delayed at all...

10-18-2011, 05:45 PM	#15
davrays Quadro Architect Join Date: Jun 2006 Location: Around myself Posts: 2,083	Let me understand first: 1. In this logs the messages are sent from "QuadroIP" to "QuadroIP", so there is just one IP address, and the IP of Asterisk server (is that the ITSP?) is not visible. How that happened? Did you replace two different IP addresses in logs with the same "QuadroIP" word? 2. There is no ringing at all in those logs. The quadro accepted the call almost immediately, and there is no ringing process. What was the destination of the call - is that an Autoattendant, or voicemail, or FXS phone or something different? To be short, could you please describe the call by words (what was the calling device; was the call from ITSP or some other device; what was the destination; how long it rang; how long you waited until hanging up the calling phone; when did you hangup - during the ringing, or when the call was already established)?

10-19-2011, 09:06 AM	#16
Kristoph Junior Member Join Date: Sep 2009 Posts: 21	You are right, sorry for this, similar IP addresses, my bad.

10-19-2011, 09:42 PM	#17
davrays Quadro Architect Join Date: Jun 2006 Location: Around myself Posts: 2,083	Thanks for correcting the logs.... What about my second question?

10-24-2011, 07:11 PM	#19
davrays Quadro Architect Join Date: Jun 2006 Location: Around myself Posts: 2,083	Well, if this is the test scenario, then you can clearly see in the logs above that the problem is in the SIP server (it looks to be a kind of Asterisk machine). As you tell, you have hang up the calling phone (at the Asterisk side), but we don't see any BYE message coming from the Asterisk machine. Thats why Quadro is not informed that you have hangup the calling phone, and so the call stays active on the Quadro (so you have a voicemail recorded). After timeout the call was closed by Quadro itself, and you can see at this point the Astreisk server told it doesn't know anything about that call ("481 Call leg/transaction does not exist" message). So my assumptions are the following: It looks like the Asterisk machine have closed this call locally after getting "488 Not Acceptable Here" response ftrom Quadro at 14:27:15. But Asterisk did that silently, without sending any "close" message to Quadro. This is incorrect behaviour from that server machine side (as it SHOULD send "BYE" message). I suppose this is a bug in that server software. Now about what you can do to fix this problem: 1. you either have to find somebody to fix the problem in Asterisk (so it doesn't silently close the call after getting "488 Not Acceptable Here"), or 2. find out why the Asterisk server sends the mid-call re-INVITE message at 14:27:15, which causes this problem (as it causes Quadro to send the 488 response), and configure the server not to send those re-INVITES. I suppose this could be some kind of session timer initiated from Astyerisk machine. Probably you have to disable that. In any case - you have to look for the problem in the Asterisk server software, but not in the Quadro.

10-26-2011, 10:02 AM	#20
Kristoph Junior Member Join Date: Sep 2009 Posts: 21	I will contact the SIP provider and show them the conclusion you came to, hopefully they can fix the problem. Thank you for your time!

Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)
